HELIUX LITE

Payload for manned aerial inspection, surveying, and mapping.

HELIUX LITE geospatial data-collection system mounted on Cessna 172 for corridor mapping (power lines, pipelines, roads etc.) application.

AISPECO HELIUX LITE is the exclusive solution on the market, uniquely combining advanced cameras and stabilizers for light aircraft like Cessna and helicopters like Robinson. Available in a variety of configurations, from optical cameras with LiDAR to advanced stabilization kits, AISPECO systems are ideal for aerial inspection flights, corridor mapping, wide area surveying, and other geospatial data-collection tasks. Our systems support a range of sensors, including spectral (hyperspectral) imaging capabilities and airborne laser scanning (LiDAR), ensuring precise and reliable mapping and surveying outcomes.

HELIUX LITE geospatial data-collection system mounted on Robinson R44 for corridor mapping (power lines, pipelines, roads etc.) application.
HELIUX LITE data-collection system mounted on Cessna 172 for corridor mapping (power lines, pipelines, roads etc.) application.
HELIUX LITE geospatial data-collection system mounted on Cessna 172 for corridor mapping (power lines, pipelines, roads etc.) application.
HELIUX LITE geospatial data-collection system mounted on Cessna 172 for corridor mapping (power lines, pipelines, roads etc.) application.
HELIUX LITE geospatial data-collection system mounted on Robinson R44 for corridor mapping (power lines, pipelines, roads etc.) application.
HELIUX LITE geospatial data-collection system mounted on Cessna 182P for corridor mapping (power lines, pipelines, roads etc.) application.

Benefits

STC'd mounting options

  • Aerial data-collection systems come equipped with FAA/EASA (and other authorities) approved mounting options, making them compatible with most popular helicopter and airplane models without the need for any modifications.

Mix & match

  • Mix & match system allows customers to install various camera, sensor, and LiDAR setups at different angles, enabling them to customize their configurations to meet specific project needs.

User-changeable sensors’ configurations

  • Our system provides the flexibility of user-changeable sensor configurations, allowing for easy customization and adaptation of data-collection methods. This innovative feature lets users modify or upgrade individual sensors without the need to replace the entire system.

Fits in airline luggage

  • AISPECO systems can be conveniently packed into custom-made pelican cases that meet airline luggage requirements, allowing users to travel together with the system and confidently bring it on fieldwork or business trips.

Applications

AISPECO systems are designed for multiple applications. Ideal for:

  • City mapping
  • Defense
  • Infrastructure
  • Agriculture
  • Forestry

Specifications

Max payload weight: 50 lbs.

Max payload frontal area: 1 sq. ft.

Operating temperature: -20 ° up to +50 °

Max operating AGL: 9000 ft

Average power consumption: 150 w

Flight management software: AISPECO or 3rd party FMS

Internal memory: up to 8 TB swappable SSD

Communications: Thin, fiber, optics cable

Main computer: Intel® Core™ i7 based SBC

Auxiliary computer: NVIDIA® Jetson Orin™

Mounting

  • EASA , FAA approved STC mounting ((nose mount, wing strut, hole in fuselage) options for:

Cessna:

  • 172, 182, 206, 208 Caravan

Diamond:

  • DA42

Robinson:

  • R44, R66

Bell:

  • 206

MD:

  • MD500

Airbus:

  • AS350 family
  • and more...

Combine sensors for different use cases

User changeable sensors’ configurations

Equipped with:

  • Riegl VUX-240 LiDAR scanner
  • 2x Sony Alpha 1
  • PhaseOne iXM-GS120
  • Applanix AP+50

Mounted on:

  • Cessna 182

Aplication:

  • Corridor mapping and area surveys
HELIUX LITE geospatial data-collection system mounted on Cessna 182 for corridor mapping (power lines, pipelines, roads etc.) application.

Equipped with:

  • Riegl VQ580-II-S LiDAR scanner
  • Sony ILX-LR1
  • Applanix AP+50

Mounted on:

  • Cessna 172

Aplication:

  • Coastal
HELIUX LITE geospatial data-collection system mounted on Cessna 182P for corridor mapping (power lines, pipelines, roads etc.) application.

Equipped with:

  • Sony Alpha 1
  • Custom made gimbal
  • Applanix AP+18 EI

Mounted on:

  • Robbinson R44

Aplication:

  • Pipelines
HELIUX LITE geospatial data-collection system mounted on Robinson R44 for corridor mapping (power lines, pipelines, roads etc.) application.

Dimensions

The HELIUX LITE is a comprehensive solution for aerial inspection, surveying, and mapping. Configurable with optical cameras, LiDAR, and stabilization kits, it ensures precise and efficient geospatial data collection for light aircraft.
